An evolving CAD foundation
Unit CAD
Parametric solids, parts and assemblies as a foundation for product development.
Explore Unit CAD
UNIT CAD / Connected engineeringFrom your voice.
Conceptual engineering visualFrom your voice.
To manufacturing.
An integrated vision for parametric CAD, AI and engineering. From the first idea to the complexity of a product, with you in control.
In development. Illustrative 3D experience, not a CAD demonstration.
One vision. Three pillars.
Connect every part of your process.
Engineering goes beyond good geometry. Unit CAD is evolving to bring modeling, intent and technical decisions together in one product vision.
Planned integration
Unit AI
A copilot planned to turn intent into actions you can review and approve.
Discover Unit AIPlanned architecture
Engineering Core
A planned architecture to connect requirements, calculations and decisions throughout the design process.
Explore Engineering CoreCAD foundation as reported by the team, without an independent audit. Unit AI and Engineering Core are planned integrations. No public release has been announced.
UNIT AI / Development visionYour intent.
Your intent.
The engineer in control.
Describe what you want to build. The vision for Unit AI is to interpret requirements, propose operations and coordinate tools—with human review, traceability and approval.
Explore the vision for Unit AIExplore Engineering CoreFrom intent to decisionConcept
01 / DefineGoal and constraints
Your needs guide the design.
02 / ProposeAn operations plan
AI is intended to propose; the engines are intended to calculate.
03 / ApproveThe decision is still yours
Review the assumptions before moving forward.
Illustrative workflow. No commands are executed on this page.
Designed to expand possibilities
All applicationsDifferent challenges. One engineering vision.
01Machines and products
From the first component to the logic of a complete assembly.
Explore the application
02Components and manufacturing
Geometry and documentation with the production process in mind.
Explore the application
03HVAC specialization
The first planned vertical: equipment, technical data and engineering engines.
Explore the applicationAI-generated concept images. Not software screenshots or designs validated for manufacturing.
Information for your next step
Explore. Understand. Participate.
Explore the product direction and find the information you need to decide.
Clarity before you begin
The next step starts with clear answers.
Product stage, integrations and availability. A clear distinction between the vision and what exists today.
All questionsUnit CAD is a professional 3D parametric and multidisciplinary CAD platform to develop products, machines and equipment. The team reports an existing CAD base; Unit AI and Engineering Core are the next planned layers. HVAC will be the first major specialization, not a usage limit.
As reported by the team, the base includes solids, parametrics, reconstruction-enabled assembly tree, extrusions, cuts, surfaces, planes, sheet metal, hems, bends, unfolds, flat patterns, DXF and assemblies. Advanced assembly relations and 2D engineering drawings are in improvement. This presentation does not constitute a code audit nor independent validation.
Voice and text operation is planned for Unit AI. It should interpret requirements and command tools via the CAD's controlled APIs, with previews, ambiguity confirmation and reversible history. The site examples are illustrative, not an operational voice interface.
THE NEXT CHAPTER IS COLLABORATIVE
What do you want
to create next?
Your experience can help shape what comes next.
